| BRAND | S+S REGELTECHNIK |
| Product | 1101-31D2-0069-810 |
| Description | Duct/ smoke gas temperature measuring transducer |
| Internal code | 4621494 |
| Technical specification | RGTM1-I 300MM KV Power consumption < 1.0 VA/ 24 V AC/ DC; < 0.55 VA/ 24 V DC Voltage supply 15...36 V DC depending on working resistance, residual ripple stabilised ± 0.3 V Working resistance máx. 750 Ohm/ 24 V DC Temperature deviation typically ± 0.2 K at +25 °C Sensor Pt1000, DIN EN 60751, class B, glass sensing resistor (Perfect Sensor Protection) Connection type 2- or 3-wire connection Measuring ranges multi-range switching with 8 switchable measuring ranges, see table (other ranges optional) with manual zero point correction (± 10 K) Ambient temperature Measuring transducer –30...+70 °C Process connection by mounting flange, stainless steel V2A (1.4305) (included in the scope of delivery) Protective tube stainless steel, 1.4571, V4A, Ø = 8 mm Electrical connection 0.2 - 1.5 mm², via push-in terminal Connecting head form B, material aluminium, colour white aluminium (similar to RAL 9006), M 20 x 1.5 Output 4...20 mA Permissible air humidity < 95 % r. H., non-precipitating air Protection class III (according to EN 60 730) |
Please Contact Us to Order to offer competitive prices and delivery time for S+S REGELTECHNIK - 1101-31D2-0069-810 Duct/ smoke gas temperature measuring transducer number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
