| BRAND | Buschjost |
| Product | 3/045-23-0815-.272 |
| Description | 3/2-way solenoid valve |
| Internal code | 4932022 |
| Custom code | 84818073 |
| Technical specification | G073,000380.042,099.040 for connection to 220V DC (with blind screw connection) as 2/2 way, not included) Control type: directly controlled, differential pressure min. 0 bar Construction: seat valve with plate seal Function: universal design (any connection can be pressed .: be charged) Connection: 1/2" cyl. IG according to ISO 228/1 Seat: 10.0 mm Pressure: 0 - 200 bar Temperature (medium): -30°C/+80°C Temperature (ambient): -10°C/+35°C Viscosity (max): 22 mm²/s Material (housing): stainless steel 1.4571 Material (in contact with media): stainless steel 1.4571 Seal: PEEK seat seal, rest PTFE/FKM Installation: drive in a horizontal or upright position B0051.000365 with magnetic coil Type: .272 (K0512740) Voltage: 220V DC Dust/water protection: IP65 Power: 100W Duty time: 100% ED Connection type: terminal box with M16x1.5 cable screw connection Cable clamp area: Ø5-10mm |
Please Contact Us to Order to offer competitive prices and delivery time for Buschjost - 3/045-23-0815-.272 3/2-way solenoid valve number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
