| BRAND | Baelz |
| Product | 373-E07-20-18-5301 + 99.0S373-923 |
| Internal code | 3905591 |
| Custom code | 84819000 |
| Technical specification | Digital engine lift drive steadily 2000 N; 18 mm/min; 230 V, 50/60 Hz 373-E07-20-18-S21-mf-fg5k-7020-230 self-adapting 1 input signal: 0/2... 10 V or 0/4... 20 mA delivered condition: 0... 10 V 2 output signals: output 1:0... 10 V and output 2:0... 20 mA or output 1:2... 10 V and output 2:4... 20 mA Delivery condition: 0... 10 V and 0... 20 mA 1 digital input freely adjustable via software 2 relays freely adjustable via DIP switches auxiliary switch contacts 12... 250 VAC Interface: RS 485 Modbus RTU 1 multispiral potentiometer 5 kohms incl. drive stand and clutch (S21) KT7980 for control valves with spindle diameter 10 mm IP 42; stroke max. 22 mm 230 V, 50/60 Hz Net weight: 2.4 kg |
Please Contact Us to Order to offer competitive prices and delivery time for Baelz - 373-E07-20-18-5301 + 99.0S373-923 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
