| BRAND | Fairchild |
| Product | 4514A |
| Description | Model 4500A Pneumatic Volume Booster 1:1 ratio |
| Internal code | IMP3315139 |
| Weight | 1.81437 |
| Custom code | 8412 3900 90 0 |
| Technical specification | Accuracy: 0.50 psi Ambient Temperature: -40° to 200 °F (-40° to 93.3 °C) Base Model: 4514A Body Material: Aluminum Connection Size: 1/2 in. NPT Elastomer: Nitrile on Dacron Exhaust Capacity: 40 SCFM [65.2m³/hr] where downstream pressure is 5 psi above 20 psi setpoint Exhaust Type: Straight (standard) Flow Capacity: 150 SCFM (255 m³/hr) FlowCv: 3 Max. Output Pressure: 150 psig Max. Supply Pressure: 250 psig Mounting: Wall (20555-1 bracket required) Operator: Pneumatic Pilot Signal Options: None Pipe Size: 1/2 FPT Pressure Range: 0 to 150 psi Product Type: Pneumatic Volume Boosters Ratio: 1:01 RatioAccuracy: 3.0% of 100 psi output span Sensitivity: 1 in. WC Signal to Output Pressure Ratio: 1:01 Supply Pressure: 250 psi Product Category: Pneumatic Volume Boosters |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Fairchild - 4514A Model 4500A Pneumatic Volume Booster 1:1 ratio number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
