| BRAND | Combimac |
| Product | 51DZK475/R2K1 |
| Internal code | IMP1476054 |
| Weight | 62 |
| Technical specification | <p>- part number = 847.568 -- weight = 62 kg - max. Medium temp. = 60ºC - housing material = cast iron - impeller material = stainless steel AISI316 - graphic = 51A471/CJ1 - execution = ATEX Ex II 3G IIB c T3 (Inside) = ATEX Ex II 3G IIB c T3 (Outside) - guideline = NEN-EN14986 - leakage test procedure = CN3022 </p><p>TECHNICAL INFORMATION MOTOR: - voltage = 400V - 3 ph - power = 1,1 kW - insulation class = F - frequency = 50 Hz - speed (synchr.) = 3000 rpm - frame = IEC 100L - ambient temp. (max) = 40ºC - protection class = IP55 - type = ATEX Ex-II-2G Ex-eb-II-T3 - dimension = D.004.319</p> |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Combimac - 51DZK475/R2K1 number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
