| BRAND | Airtec |
| Product | 59560 |
| Description | 5/2-way NAMUR solenoid valve |
| Internal code | IMP4350462 |
| Weight | 0.32 |
| Custom code | 84812090 |
| Technical specification | 59560 5/2-3/2.KN-05-510-P1067-142-24/DC 5/2-3/2 way Flex NAMUR solenoid valve, series KN-05, piston valve with air spring, rest position closed, monostable, connection: G1/4, Namur, nominal size: 6mm, temperature range: -10°C to +70°C, housing: anodized aluminum, plastic, seals: NBR and OPM, internal parts: aluminum, stainless steel and brass, operating pressure: 3 to 10bar, flow rate: 900 Nl/min, protection class: IP65, with emergency manual operation, with coil and power outlet, DC 24V, included 86-4-AP-NAMUR turning plate for 3/2-way function and Connecting screws 2x 24-08-12-05 5/2-way NAMUR solenoid valve, series KN-05, electrically Operated spool valve with air spring, normal close, single solenoid, connection: G1/4, Namur, nominal size: 6mm, temp. range: -10°C.. +70°C, body: anodized aluminum, plastic, seals: NBR, inner parts: aluminum, steel and plastic, operating pressure: 3 - 10 bar, flow rate: 900 Nl/min, protection: IP65, with manual override, with coil And plug, DC - 24V, including converting plate type 86-4-AP-NAMUR to convert into 3/2-way function, within Assembling screws 2x 24-08-12-05 WT/CT: 8481 2090/EN |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Airtec - 59560 5/2-way NAMUR solenoid valve number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
