| BRAND | Buschjost |
| Product | 8240214.9101.02400 |
| Description | 2/2-way solenoid valve |
| Internal code | IMP4017974 |
| Weight | 0.497 |
| Custom code | 84818079 |
| Technical specification | Model series 82400 Description 2/2-way solenoid valve Type diaphragm valve Control controlled indirectly G 1/2 connection PN 16 pressure level Nominal diameter 12 mm Pressure range 0.3 - 16 bar Electrical outlet type A kV value 3.80 m³/h Medium temperature -10 to +110°C Ambient temperature -10 to +50°C Voltage 24 V Frequency 00 Hz Protection class IP 65 Suit 8 W 8 W operating mode Including duration 100% Any installation option, preferably electrical Magnet vertically upwards Brass wst housing EPDM water seal Switch function closed in rest position Additional info Magnet with CSA approval mark in accordance with C/US Standards |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Buschjost - 8240214.9101.02400 2/2-way solenoid valve number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
