| BRAND | Vivoil Oleodinamica Vivolo |
| Product | X2F4502QOOA / 022-080-01200 |
| Description | pump |
| Internal code | IMP1808788 |
| Weight | 2.4 |
| Custom code | 84136031 |
| Technical specification | XV2F/9D-Ø36.5-SCF.01-30/30 8.4 ccm/U - clockwise - 260 bar End section external gear pump size 2 with aluminum body and aluminum flanges Delivery volume: 8.4 ccm/U Direction of rotation: clockwise Mounting flange for previously installed pump size 2: Passage Ø 36.5 mm - 4 hole mounting 96.2 mm x 71.5 mm Drive shaft: 9 teeth DIN5482 - 17x14 - Ø 16.5 h11 Suction connection: LK 30 mm - M6 x 1 Pressure connection: LK 30 mm - M6 x 1 Installation length: 94.2 mm Sealing material: NBR Allowable shaft torque: 86.2 Nm Continuous pressure limited by drive shaft: 260 bar Continuous pressure: 260 bar Peak pressure (max 0.5 sec.): 300 bar Minimum speed: 700 rpm Maximum speed: 3500 rpm |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Vivoil Oleodinamica Vivolo - X2F4502QOOA / 022-080-01200 pump number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
