| BRAND | Vivoil Oleodinamica Vivolo |
| Product | X2P5102EPOA |
| Description | external gear pump |
| Internal code | IMP1699279 |
| Weight | 3 |
| Custom code | 84136031 |
| Technical specification | Size 2 with aluminium body and aluminium flanges Conveying volume: 16.8 ccm/rev Rotation direction: clockwise Mounting flange: Fitting Ø 36.5 mm - 4 hole mounting 96.2 mm x 71.5 mm - Ø 9 mm Drive shaft: conical 1:8 - disc spring 4 mm Intake connection: LK 40 mm - M8 x 1.25 Pressure connection: LK 30 mm - M6 x 1 Installation length: 108.2 mm Sealing material: NBR Permissible shaft torque: 233,2 Nm Continuous pressure limited by drive shaft: 250 bar Permanent pressure: 230 bar Peak pressure (max. 0.5 sec): 270 bar Minimum speed: 700 rpm Maximum speed: 3500 rpm |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Vivoil Oleodinamica Vivolo - X2P5102EPOA external gear pump number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
