| BRAND | Honsberg |
| Product | CR-025.MVS.IP65 |
| Description | Flow switch |
| Internal code | IMP5085973 |
| Weight | 0.7 |
| Custom code | 90261029 |
| Technical specification | <p>Brass body<br>1" Gas-M conical UNI 7/1 process connection - DIN 2999<br>Suitable for mounting DN25... DN200 intubations<br>Stainless steel scoop<br>Fold-down sealing element in rump<br>Max working pressure 10 bar static/30 bar dynamic<br>Max working temperature 120°C<br>Adjustable calibration range depending on the DN of the pipe and<br>From the size of the scoop used<br>See technical data sheet<br>Pressure loss at maximum recommended flow rate 0.08 bar<br>ABS electric case<br>PG 13.5 cable entry<br>SPDT micro switch<br>Maximum electrical loads: 250Vca/15A<br>Degree of protection IP65</p><p>ns. cod. 08.0001.0065</p> |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Honsberg - CR-025.MVS.IP65 Flow switch number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
