| BRAND | Almatec |
| Product | CXM20FES |
| Description | pump |
| Internal code | IMP4356151 |
| Weight | 1.8 |
| Custom code | 84135069 |
| Technical specification | Wilden Almatec CXM20 FES Pump “E-Series - More Performance - Even Safer” with pneumatic double diaphragm drive (delivered) with exhaust silencers) Body and seats Conductive polyethylene FDA approved carbon-filled PE resin Nordel EPDM membrane with integrated piston (ATEX) Nordel EPDM stainless steel balls and seals. PE seats cond. Chambers on the air side and central PE conductor block. <! > reduction of the maximum temperature of the pumped fluid at 80°C for metal or PTFE pumps, PE pumps are already limited to 70°C (subject to chemical compatibility). Perswing® anti-stalling design air distribution, works with dry, non-lubricated air, filtered to 5µm. Bolted and stainless steel pressure disc assembly 1.4301 (AISI 304) for a better distribution of efforts and reinforced tightness. Asp. connection (horiz)/Ref. (green.): 1/2" NPT f Air connection: 1/4” BSP Complies with ATEX 94/9/EG standard CE Ex II 2 gDC IIB T70°C |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Almatec - CXM20FES pump number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
