| BRAND | Bd Sensors |
| Product | DMP 331P |
| Description | Industrial Pressure Transmitter |
| Internal code | IMP3389126 |
| Weight | 0.2 |
| Technical specification | Code: 500-2501-1-3-100-Z00-1-1-2-000 Device type: DMP 331P Measurement variable: relative Input code: 0... 2.5 bar El. Output: 4... 20 mA/2-wire Supply: 8... 32 VDC Accuracy: 0.35% FSO IEC Supply +: 1 Supply -: 2 Screen: Grounding Protection class: IP65 Mech Connection: G 1/2" flush with the front, DIN 3852 Separating membrane: stainless steel 1.4435 (316L) Seal: FKM Filling liquid: Food-grade oil Special design: Standard membrane position: membrane downwards Calibration temperature: 20 °C Type plate: BDS GmbH Type plate - Position: Standard El. Connection: plug and cable socket ISO 4400 |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Bd Sensors - DMP 331P Industrial Pressure Transmitter number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
