| BRAND | Stober |
| Product | F102SGN0185ME10 |
| Internal code | IMP5123745 |
| Weight | 11.5 |
| Custom code | 84834021 |
| Technical specification | <p>Article: MV0000147493</p><p>Parallel shaft gearbox with motor adapter</p><p>Ratio 18.46</p><p>Exact math ratio 1495/81</p><p>Nominal torque 110 Nm</p><br><p>Max. acceleration torque allowed 120 Nm</p><br><p>Max. continuous input speed 3700 rpm</p><br><p>Motor speed 1,500 rpm</p><br><p>Input speed max. cycl. 6,000 rpm</p><br><p>Game 11 Arcmin</p><br><p>Val. character of the load 1.0</p><br><p>As a replacement for serial number 10569934.</p><br><p>Tree model Hollow shaft a. Frette de ser.</p><br><p>Shaft dimension Ø20/20*99208</p><br><p>Shaft/sprocket position Clamping ring side 6</p><br><p>Cercle housing model + lateral attachment</p><br><p>EL1 mounting position</p><br><p>Model: Coupling: Clamping Coupling</p><br><p>Motor shaft diameter 9 without key</p><br><p>Max. motor shaft length Min. 21 mm - max. 41 mm</p><br><p>Model: coupling housing: Two pieces (e.g. engine parts)</p><br><p>Motor connection □ 100 40/63 M4 c=21 213799</p><br><p>270° clamping screw access</p><br><p>Mobilgear 600 XP 220* lubrication</p><br><p>CLP ISO VG 220</p><br><p>K lacquer/1-coat lacquer</p><br><p>Color RAL 9005 ink black</p><br><p>Lacquer options Side 3+4+5 unlacquered</p><br><br> <p><br></p> |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Stober - F102SGN0185ME10 number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
