| BRAND | AC Motoren |
| Product | FCA 71 B-2 / HE B5 |
| Description | AC three-phase synchronous motor |
| Internal code | IMP3412295 |
| Weight | 8 |
| Custom code | 85014080 |
| Technical specification | 106372 Motor power: 0.55 KW/S1 number of motor poles: 2 motor voltage: 3 x 230/400 V +- 10%, 50 Hz 3 x 265/460 V +- 10%, 60 Hz Motor speed: 2745 min-1/50 Hz 3294 min-1/60 Hz Rated motor current: 2.27/1.31 A Efficiency class: IE2 Efficiency: 74.1 - 74.1 - 72.6% at 4/4 - 3/2 - 2/4 load cos phi: 0.82 Degree of protection: IP 55 Insulation class: F Type: IM B5 (Please check! ) flange size: 160 x 130 x 110 mm Motor shaft: 14 m6 x 30 mm terminal box location: top Coolant temperature: -20 to +40 °C Installation height: < 1000 m above sea level Colour: RAL 7030 stone grey aluminum Additional equipment: without |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for AC Motoren - FCA 71 B-2 / HE B5 AC three-phase synchronous motor number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
