| BRAND | AC Motoren |
| Product | IE2AC13M4004 |
| Description | Three-phase asynchronous motor |
| Internal code | IMP3382880 |
| Weight | 55.2 |
| Technical specification | FCA type designation Engine type 3~ Case material AL Model size 132 Eff.Cl. 50Hz IE2 Eff.Cl. 60Hz IE2 B5 design 300 flange Power 1 50Hz 7.50 kW Power 1 60Hz 9.00 kW Circuit type Δ/Y Voltage 50Hz 400/690 V Voltage 60Hz 460/795 V Number of poles 4 Speed 1455/1746 rpm Weight 55.20 kg Frequency 50/60 Hz Insulation class F/B Ambient temperature -20 to +40 °C Wave end 38 x 80 mm RAL7030 colour Terminal box layer at the top AS Protection class IP55 Specification of BS plastic fan blades S1 operating mode AS 6308.ZZ.C3 ball bearing BS 6308.ZZ.C3 ball bearing Storage AS floating warehouse BS floating warehouse storage |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for AC Motoren - IE2AC13M4004 Three-phase asynchronous motor number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
