| BRAND | Ascon |
| Product | M1-3000-0200 |
| Description | Control thermostat series M1 |
| Internal code | IMP4163136 |
| Weight | 0.25 |
| Custom code | 90328900 |
| Technical specification | M1-3000-0200 AIN version M1 series temperature controller A.No.: G.No.: Country of origin:Italy Customs tariff number:90328900 Front: 48 x 48 mm supply voltage: 100... 240 V, 50/60 Hz Main output OP1: relay Auxiliary output OP2: relay or logic Serial port: without Interface protocol: without Actual value output OP4: without User manual: German Front color: dark gray You can freely configure as follows: input: PT100; thermocouple type l, J, T, K, S; 0 (10)... 50 mV DC OP1 output: relay (2A/250V closer) OP2 output: relay (2A/250V closer); Logic (0/5VDC, + -10%, 30mA max.) Selection by internal jumper OP4 output: without control: PID, heating or cooling, Assignment: 1 output to control and 1 output as an alarm or both outputs as an alarm Options: actual value output, transmitter supply or serial port |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Ascon - M1-3000-0200 Control thermostat series M1 number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
