| BRAND | Interroll |
| Product | MI-DM0080 DM0802-AAM1BB083JDV-252mm |
| Internal code | IMP5019400 |
| Weight | 7.11 |
| Technical specification | Product name DM 0080 Synchron Protection level IP 69K Tube length (SL) 245.0 mm Drum width (FW) 252.0 mm Installation length (EL/LW/BF) 257.0 mm Total axle length (AGL) 282.0 mm Power 425 W Winding number of pins 8 Torque [Nm] 46.8 Band tensile force 1,145 N Gear ratio (i) 38.50 Gear material description steel: 16MnCr5/AISI 5115 Speed at frequency 1 0.33 m/s Frequency 1 200 Hz external connection diagram M90 high voltage 400 V Rated current, high voltage 1.32 A Stainless steel pipe material: 1.4301/304 Tube diameter (A) 81.7 mm Tube diameter (B) 81.7 mm Wedge steel tube shape Pipe option type wedge steel spot welded 4x4mm wedge steel pipe option Wedge steel tube length 195.0 mm Cover A standard version Cover B standard version Cover A Material stainless steel: 1.4301/304 Cover B material stainless steel: 1.4301/304 Wave A standard version Ø30mm Shaft B version standard Ø30mm Wave A material stainless steel: 1.4305/303 Wave B material stainless steel: 1.4305/303 Wave A key. Area width (F) 25.0 mm Wave B key area (F) 25.0 mm Wave A key. Surface length (C) 12.5 mm Wave B key surface length (C) 12.5 mm Oil type synthetic food oil Viscosity 150 Electrical connection straight screw connection Elec. Connection material stainless steel: 1.4301/304 Power cable length 10.0 m Power cable type shielded; halogen-free min. ambient temperature -25 °C max. ambient temperature 40 °C |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Interroll - MI-DM0080 DM0802-AAM1BB083JDV-252mm number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
