| BRAND | Coax |
| Product | Type: MK 20 NC d (0-16 bar) |
| Description | 2/2-Way Direct-Acting Coaxial Valve, Normally Closed |
| Internal code | IMP4730920 |
| Weight | 5.5 |
| Custom code | 84818079 |
| Technical specification | <ul><li><strong>Model:</strong> MK 20 NC</li><li><strong>Manufacturer:</strong> Coax</li><li><strong>Type:</strong> 2/2-Way Direct-Acting Coaxial Valve</li><li><strong>Function:</strong> Normally Closed (NC)</li><li><strong>Nominal Diameter:</strong> DN 20</li><li><strong>Connection Size:</strong> G 3/4" to G 1 1/4" threads</li><li><strong>Pressure Range:</strong> 0-16 bar</li><li><strong>Flow Rate (Kv):</strong> 8.4 m³/h</li><li><strong>Media:</strong> Suitable for gaseous, liquid, highly viscous, gelatinous, and contaminated media</li><li><strong>Flow Direction:</strong> A → B as marked</li><li><strong>Switching Cycles:</strong> 150 cycles/min</li><li><strong>Switching Time:</strong> Opening: 110 ms; Closing: 110 ms</li><li><strong>Media Temperature:</strong> -20°C to +100°C</li><li><strong>Ambient Temperature:</strong> -20°C to +80°C</li><li><strong>Weight:</strong> Not specified</li><li><strong>Nominal Voltage:</strong> 24 V DC; 230 V AC (40-60 Hz)</li><li><strong>Protection Class:</strong> IP65</li><li><strong>Features:</strong> Compact design, pressure-balanced, high switching cycles, optional limit switches and manual override.</li></ul> |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Coax - Type: MK 20 NC d (0-16 bar) 2/2-Way Direct-Acting Coaxial Valve, Normally Closed number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
