| BRAND | Honsberg |
| Product | MR1K-020GM004-212 |
| Description | Flow Switch |
| Internal code | IMP5104618 |
| Weight | 1.1 |
| Custom code | 85365080 |
| Technical specification | Indicator options: Without mechanical indicator Nominal diameter: DN 20 - G ¾ Connection type: Female thread Connection material: Nickel-plated brass Pressure resistance: PN 200 Internal parts: Stainless steel Seals: NBR Average temperature: -20... +120 °C Ambient temperature: -20... +70 °C H2O switching range: 0.4... 4 l/min H2O Switching head: Plastic, flat head Adjustment: Oblong hole Electrical connection: For round plug connector M12x1, 4-pin Electrical contact: Reed switch Max. contact load: 24 V DC 1.5 A 50 W Connection diagram: normally-open contact, diode, connection Diagram No. 0.395 Protection type: IP65 Flow direction: Horizontal from the left Signal lamp: Green/yellow in the switching head |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Honsberg - MR1K-020GM004-212 Flow Switch number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
