| BRAND | J+J Automation |
| Product | P/N: S4C000109, Type: J4C-S20 |
| Description | Electric drive |
| Internal code | IMP5033817 |
| Weight | 2 |
| Custom code | 85437090 |
| Technical specification | Standard F03/F04/F05 *14mm 2x SPST NO silver contacts (5A 125VAC/3A 250VAC) and 2 path limit switches Working torque: 20 Nm/Breakaway torque: 25 Nm Swivel angle: 0°-90° (freely adjustable) Supply voltage: S= 24-240V DC/AC (50/60Hz) Brushless motor with long life, 75% ED Mount (ISO5211): F03/F04/F05 *14mm double square Ambient temperature: -20°C/+70°C Protection class: IP67, robust PA6 plastic housing Plug: 4-pin valve plug type A/CI |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for J+J Automation - P/N: S4C000109, Type: J4C-S20 Electric drive number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
