| BRAND | Woerner |
| Product | 100KUI-A01 |
| Description | Volumetric flow indicator |
| Internal code | IMP4161361 |
| Weight | 0.835 |
| Custom code | 90261089 |
| Technical specification | General: The position of the float can be monitored electrically. On the float is a permanent magnet. From the magnetic field The magnet becomes the analog transmitter This refers to the person located outside the oil flow in the control element. If the flow rate in the KUI changes, Does the current in the analog output change, each by float height (see diagram). Electrical data: Power supply: max. 30 VDC Power consumption: <1 W Protection class: DIN EN 60529 IP67 temperature range: -20... +70 °C Electr. Connection: plug M12x1, 5-pin Material: aluminum, blue anodized Weight: 0.015 kg |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Woerner - 100KUI-A01 Volumetric flow indicator number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
