| BRAND | Celesco |
| Product | PT9510-0200-121-1110 |
| Description | Heavy Industrial Cable-Extension Position Transducer with 200-inch Measurement Range and 0–10 VDC Output |
| Internal code | IMP4718933 |
| Weight | 2.548 |
| Technical specification | <ul><li><strong>Model:</strong> PT9510-0200-121-1110</li><li><strong>Manufacturer:</strong> Celesco (TE Connectivity)</li><li><strong>Type:</strong> Heavy Industrial Cable-Extension Position Transducer</li><li><strong>Measurement Range:</strong> 200 inches (5080 mm)</li><li><strong>Output Signal:</strong> 0–10 VDC</li><li><strong>Accuracy:</strong> ±0.12% full stroke</li><li><strong>Repeatability:</strong> ±0.05% full stroke</li><li><strong>Resolution:</strong> Essentially infinite</li><li><strong>Measuring Cable:</strong> Ø0.034-inch (Ø0.86 mm) nylon-coated stainless steel</li><li><strong>Enclosure Material:</strong> Powder-painted aluminum or 303 stainless steel</li><li><strong>Operating Temperature Range:</strong> -40°F to 200°F (-40°C to 90°C)</li><li><strong>Protection Class:</strong> NEMA 4/4X/6, IP67/68</li><li><strong>Features:</strong> Operates from an unregulated 14.5 to 40 VDC power supply; provides a regulated output signal over its full extended range; installs in minutes and functions properly without perfectly parallel alignment; compact design measuring only 6 inches when the cable is retracted</li></ul> |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Celesco - PT9510-0200-121-1110 Heavy Industrial Cable-Extension Position Transducer with 200-inch Measurement Range and 0–10 VDC Output number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
