| BRAND | Idec |
| Product | RJ1S-CL-D24 |
| Description | Relay Plug |
| Internal code | IMP412461 |
| Weight | 0.02 |
| Custom code | 85364190 |
| Technical specification | Relay type electromagnetic Contacts configuration SPDT Nominal coil voltage 24V DC Contact current max. 12A Contact rating AC @R (with ohmic load) with ohmic load 12A/250V AC DC @R contact rating (with ohmic load) with ohmic load 6A/30V DC Switching voltage max. 125V DC, max. 250V AC Industrial relay version Base mounting RJ relay series Operating temperature -40... 70°C Outer dimensions 31.1x12.7x27mm Coil resistance 1.08kΩ coil current 25.7mA AgSnO2 contact material Optional equipment LED control display Number of poles 5 nominal voltage For products in the Cables and Wires category, a digital/digit spelling means the following: Nominal voltage U0/U where: U0 = nominal voltage between the conductor and the metal jacket or the ground U = nominal voltage between the phase conductors 250V AC |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Idec - RJ1S-CL-D24 Relay Plug number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
