| BRAND | Texa |
| Product | TX050 |
| Description | Electronic thermostat digital controller |
| Internal code | IMP4851768 |
| Weight | 0.177 |
| Custom code | 85369095 |
| Technical specification | Container: self-extinguishing ABS Format: front 32x74 mm, depth 50 mm Mounting: panel mounting on a 71x29 mm hole Degree of protection: IP20 Front protection grade: IP65 Connections: disconnectable terminal block for conductors ri ≤ 2.5 mm2 Power supply: 230 Vac ± 10% 50/60 Hz Absorbed power: 3.5 VA max Display: two digits, red LEDs and icons Inputs: 1 NTC probe Digital input: clean contact Relay outputs: Output 1: SPDT 12A relay, 250 Vac Output 2: SPST 5 A relay, 250 Vac Data retention: on non-volatile memory (EEPROM) Type of action: 1B Pollution situation: normal Software Class: A Nominal pulse voltage: 2500 V Overvoltage category: II Operating temperature: 0÷60°C Storage temperature: -25÷60°C Relative humidity: 20÷ 85% (without condensation) Measurement and adjustment range: NTC probe -40÷110°C Resolution: 0.1°C or 1°C or 1°F Accuracy at 25°C: ±0.1°C ±1 digit |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Texa - TX050 Electronic thermostat digital controller number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
