BRAND | Calectro |
Product | UG-5-AFR-24V-ST2 |
Description | air duct smoke switch 24 V AC/DC |
Internal code | IMP4742593 |
Weight | 1.5 |
Custom code | 85311030 |
Technical specification | 24V AC/DC The Uniguard smoke detector was developed and combined to detect smoke in ventilation ducts a smoke detector with an adapter system, the pipe and housing specifically for optimal airflow were constructed by the smoke detector. The UG-5 can be used on each side of the channel in four different Positions are installed: 0°, 90°, 180° and 270°. Patented Complete delivery with air duct removal pipe, 0.6 m in length. Power supply: 24 V AC/DC -15%, +10% Smoke detector type: UG-5-AFR-24V optical Max. power consumption: 220 mA Operating temperature: -10°C to +55°C Max. humidity: 99% RH Air speed range: 1 to 20 m/s Approvals: VdS G213014, CE, prEN-54-27 Smoke alarm unlocking via remote reset Relay output: Potential-free Smoke alarm relay: Two 250 V, 8A switch contacts Service alarm: One changeover contact 250 V, 5 A System fault alarm: One changeover contact 250 V, 5 A Air speed alarm alarm: One switch contact 250 V, 5 A LED on smoke detector: Green: service alarm (contamination) Red smoke alarm LED on circuit board: Green: normal operation Yellow - system error Yellow - air speed alert Adapter housing: ABS Protection class: IP54 |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Calectro - UG-5-AFR-24V-ST2 air duct smoke switch 24 V AC/DC number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
