| BRAND | Vivoil Oleodinamica Vivolo |
| Product | X2P5702EQPA |
| Description | external gear pump |
| Internal code | IMP4819428 |
| Weight | 3.15 |
| Custom code | 84136031 |
| Technical specification | XV2P/26D-Ø36.5-CO.001-40/40 26.2ccm/U - clockwise - 170bar Size 2 external gear pump with aluminum body and aluminum flanges Delivery volume: 26.2 ccm/U Direction of rotation: clockwise Mounting flange: Passport Ø 36.5 mm - 4 hole mounting 96.2 mm x 71.5 mm - Ø 9 mm Drive shaft: conical 1:8 - disc spring 4 mm Suction connection: LK 40 mm - M8 x 1.25 Pressure connection: LK 40 mm - M8 x 1.25 Installation length: 122.2 mm Sealing material: NBR Allowable shaft torque: 233.2 Nm Continuous pressure limited by drive shaft: 170 bar Continuous pressure: 170 bar Peak pressure (max 0.5 sec.): 210 bar Minimum speed: 700 rpm Maximum speed: 3000 rpm |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Vivoil Oleodinamica Vivolo - X2P5702EQPA external gear pump number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
