| BRAND | Vivoil Oleodinamica Vivolo |
| Product | X2T6302EQPA |
| Internal code | IMP4852025 |
| Weight | 3.8 |
| Custom code | 84136031 |
| Technical specification | XV2T/40D-40/40 39.6 ccm/U - clockwise - 123 bar Front section external gear pump size 2 with aluminum body and aluminum flanges Delivery volume: 39.6 ccm/U Direction of rotation: clockwise Mounting flange: single-pass Ø 36.5 mm - 4 hole mounting 96.2 mm x 71.5 mm Mounting flange for middle or end section Size 2: single pass Ø 36.5 mm - 4 hole mounting 96.2 mm x 71.5 mm Drive shaft: conical 1:8 - disc spring 4 mm - toothed thrust 9 teeth DIN5482 - 17x14 - Ø 16.5 h11 Suction connection: LK 40 mm - M8 x 1.25 Pressure connection: LK 40 mm - M8 x 1.25 Installation length: 142.4 mm Sealing material: NBR Allowable shaft torque: 86.2 Nm Continuous pressure limited by drive shaft: 123 bar Continuous pressure: 140 bar Peak pressure (max. 0.5 sec.): 180 bar Minimum speed: 700 rpm Maximum speed: 2000 rpm” |
Please send us your request per e-mail, so we can send you our offer with competitive prices and delivery time for Vivoil Oleodinamica Vivolo - X2T6302EQPA number or any other model you need. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
|
|
