| BRAND | Baratti |
| Product | ATMOS D10-KR Var. 0102 |
| Description | Reciprocating fan pressure mode |
| Internal code | 4746639 |
| Weight | 600 |
| Custom code | 84141025 |
| Technical specification | - absolutely oil-free and wear-free compression - Labyrinth sealing to the compressor chamber with relief hole - air-cooled, V-belt drive with belt protection - Intake muffler including integrated intake filter - two-stage exhaust muffler - including pressure relief valve - including exhaust side connector, rubber sleeve and two mounting clamps - including glycerin-filled tube spring pressure gauge D = 63mm (0... 1.6bar) Technical data in general: Suction volume: 120 to 1500m3/h (15 to 75Hz) Pressure increase (continuous/intermittent): 1.4/1.8 bar abs. Fan speed: 800 to 4500min -1 (15 to 75Hz) Valve diameter DN: 100/150 Outer diameter of exhaust air outlet: 114.3 mm Inner diameter of rubber sleeve: 110mm Noise level (speed/depending on pressure) approx.: 80db (A) dB (A) (after free-field measurement DIN 45635) For dimensions, see measurement sheet no.: 900047AB Technical data for your application: Suction volume: 1130 m³/h max. overpressure: 760 mbar Safety valve set to: 800 mbar Fan speed: 2750 rpm Motor: 30 kW, 3x 400 V 50 Hz KRS engine: SPB 150-3r, TL 2517, 55mm KRS blower: SPB 160-3r, TL 2517, 40mm V-belts: XPB 1450 (3 pcs) |
Discover the superior quality and performance of the Baratti ATMOS D10-KR Var. 0102 with RADWARD LTD in United Kingdom . Whether you are looking for reliability or efficiency, this product meets all your industrial needs.
The ATMOS D10-KR Var. 0102 is designed to provide optimal performance and durability in various applications. Known for its high-quality construction and innovative features, it is a preferred choice for professionals.
Key Features of ATMOS D10-KR Var. 0102 :
At RADWARD LTD , we offer the ATMOS D10-KR Var. 0102 at competitive prices and with the fastest delivery times across United Kingdom . Our expert team is ready to assist you with all your inquiries and provide tailored solutions to meet your specific needs.
Why Choose RADWARD LTD ?
Get Your Quote Today! Ready to enhance your operations with the ATMOS D10-KR Var. 0102 ? Contact us now for a personalized quote. Fill out the form below or send us an email with your inquiry. Let us help you make a cost-effective, quality-driven choice for your business.
Important Notice: While we supply Baratti products, RADWARD LTD is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy ATMOS D10-KR Var. 0102 by Baratti in United Kingdom?
You can purchase ATMOS D10-KR Var. 0102 by Baratti from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the ATMOS D10-KR Var. 0102?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Baratti in United Kingdom?
While we are not the official distributor or seller of Baratti in United Kingdom, we source our products from reliable channels and offer you original Baratti equipment at competitive prices.
How can I access ATMOS D10-KR Var. 0102 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for ATMOS D10-KR Var. 0102 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for ATMOS D10-KR Var. 0102?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
