| BRAND | CD AUTOMATION |
| Product | CD3000S 1PH/35A/440V/480V/12-24V/SSR/ZC/NF/HB |
| Description | thyristor plate series S |
| Internal code | 1867584 |
| Weight | 0.5 |
| Technical specification | CD3S10035480024SSRHB Circuit: single phase switch, zero through switch - load current: 35 A (T40°C), 28A (T50°C) - Load voltage: up to 480 V - auxiliary voltage: 12-24 V - Control: logic 4-30 Vdc, 12 mA max. (OFF < 1 Vdc, ON > 4 Vdc) - partial load error: * partial load fault detection from 50msec. switch-on time * partial load fault detection from 80% of Nominal current * automatic measurement of the nominal current by means of a button at 100% adjustment size for approx. 1 min. - Dimensions: 52 x 120 x 120 mm (WxHxD) - ideal for heating control with ohmic load (zero passage) - antiparallel thyristor actuators - CE mark - space-saving thanks to integrated heatsink - RC link and varistor integrated - LED status indicator - DIN rail mounting or screw mounting - incl. Current transformer 50/0,05A for DIN rail mounting |
Please Contact Us to Order to offer competitive prices and delivery time for CD AUTOMATION - CD3000S 1PH/35A/440V/480V/12-24V/SSR/ZC/NF/HB thyristor plate series S number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
