| BRAND | Chinfa Electronics |
| Product | DRAN120-24A |
| Description | 1 phase primary switching controller |
| Internal code | 4051502 |
| Custom code | 85044082 |
| Technical specification | 5A TS fastening, Screw terminal connections, LED Input voltage 90-132, 186-264 VAC autom. Selection, 210 - 375 VDC 47 - 63 HZ Output voltage: 24 VDC adjustable 22.5-28.5 VDC, + -1% Power 120W / 5 A Voltage bridging at 230 Vi: 30 ms -25 ... + 71 ° C (derating from 61 ° C) Overload protection at 145%, Current Limited Short-circuit, overload and overvoltage protection, cULus, TÜV, CE Dimensions: W 63.2 x H 124 x D 116 mm |
Please Contact Us to Order to offer competitive prices and delivery time for Chinfa Electronics - DRAN120-24A 1 phase primary switching controller number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
