| BRAND | Frizlen |
| Product | FAQ3248004-3.7 |
| Description | Steel grid fixed resistor |
| Internal code | 3415895 |
| Weight | 93 |
| Custom code | 85332900 |
| Technical specification | steel lattice fixed resistance device, manufacturing tolerance +/- 10%, Ohm value change between cold and operating temperature approx. + 15%, for floor installation, in galvanised all-round sealed Sheet steel housing with safety grille at the bottom and top, without weather protection cover, connection to terminals in the device, clamps after disassembly accessible from the front cover, version according to list sheet T629, Dimensions according to drawing 16M0087 Frizlen Item Number: 32260 - Resistance, Electr. , Continuous power: 24 kW Resistance value: 3.7 ohms Protection class: IP 20 for hoist 1: max. 90 kW Resistance value: 3.7 ohms Continuous power (built-in): 40 kW (80 S05-0.047) Connection to terminals: 2 BK M8-25 Temp. switch: number/terminals: 1 pcs./ PK2 Switch card: 111961 Type plate: FRIZLEN Fixed resistor with special hole spacing LAT=425mm, with warning sign, with an additional terminal strip, with 2 additional perforated plate covers at the bottom |
Please Contact Us to Order to offer competitive prices and delivery time for Frizlen - FAQ3248004-3.7 Steel grid fixed resistor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
