| BRAND | Frizlen |
| Product | FS3122109-3X0.85 |
| Internal code | 3286400 |
| Weight | 36 |
| Technical specification | Steel-grid fixed resistor device, manufacturing tolerance of +/- 10%, resistance change between cold and operating temperature about + 15%, for floor-level mounting, in galvanized sheet steel enclosure with protective grid at the top and bottom, with weatherproof roof, suitable for outdoor location, connection to terminals in the unit, terminals accessible after removing the front cover, designed to list sheet T629E, dimensions according to sheet 16M0043 Degree of protection: IP23 Application: Starting/speed set. resistor For (motor type): slipring motor Total resistance value: 3x0.85 Ohm With taps at: 3x0.1 Ohm and 3x0.4 Ohm Connection on Terminals: 9 BK M8-25 Wiring: starpoint in the resistor as delivered with our order no.105396 |
Please Contact Us to Order to offer competitive prices and delivery time for Frizlen - FS3122109-3X0.85 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
