| BRAND | Dwyer |
| Product | L6EPB-B-S-3-B |
| Description | Liquid Level Switch |
| Internal code | 4739933 |
| Technical specification | Service Liquids compatible with wetted materials Wetted Materials Float: Solid polypropylene Lower Body: Brass Magnet: Ceramic External Float Chamber (Tee): Brass Temperature Limit -4 to 220°F (-20 to 105°C) Pressure Limits Maximum pressure 250 psig (17.2 bar) Enclosure Rating Weatherproof and explosion-proof Listed with UL and CSA for Class I, Groups A, B, C and D; Class II, Groups E, F, and G Switch Type SPDT snap switch Electrical Rating 5 A at 125/250 VAC (V~) Electrical Connections 18 AWG, 18" (460 mm) long Upper Body Brass Conduit Connection 3/4" male NPT Process Connection 1" female NPT Mounting Orientation Horizontal with index arrow pointing down Specific Gravity Minimum 0.9 |
Please Contact Us to Order to offer competitive prices and delivery time for Dwyer - L6EPB-B-S-3-B Liquid Level Switch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
