| BRAND | Ascon |
| Product | M1-3000-0200 |
| Description | Control thermostat series M1 |
| Internal code | 4163136 |
| Custom code | 90328900 |
| Technical specification | A.No.: G.No. Front: 48 x 48 mm Supply voltage: 100... 240 V, 50/60 Hz Main output OP1: Relay auxiliary output OP2: relay or logic Serial interface: without Interface report: without Actual output OP4: without Instruction manual: German Front colour: dark grey Free configuration can be configured as follows: Input: PT100; thermocouple type l, J, T, K, S; 0 (10)... 50 mV DC Output OP1: Relay (2A/250V connection) Output OP2: Relay (2A/250V connection); Logic (0/5VDC, + -10%, 30mA max.) Selection by internal jumpers Output OP4: without Control: PID, heating or cooling, Assignment: 1 output to the control unit and 1 output as alarm or both s can be used as alarm Options: Actual output, Transmitter power or serial interface |
Please Contact Us to Order to offer competitive prices and delivery time for Ascon - M1-3000-0200 Control thermostat series M1 number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
