| BRAND | Alco |
| Product | PS1-A5A 7/16"UNF |
| Description | High pressure switch |
| Internal code | 538016 |
| Weight | 1 |
| Custom code | 90322000 |
| Technical specification | Temperature data Ambient temperature -50 to +70 °C Max. temperature In the pressure connection +70 ºC Pipeline connections Flame 7/16" UNF Electrical data Starting current 230 V Motor current 230 V ohmic load 24A protection class IP 44 (according to DIN 40050/IEC 529) AC11 inductive load 20TH DC11 inductive charging 0.1A Pressure Lowest switch point 3 bars max. test pressure 35 bars Adjustment range upper switch point 6 to 31 bar lower switch point 2 to 15 bar |
Please Contact Us to Order to offer competitive prices and delivery time for Alco - PS1-A5A 7/16"UNF High pressure switch number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
