| BRAND | Helical |
| Product | S12B DM80GD4 B03MB EI02 TW |
| Description | Motor |
| Internal code | 4538720 |
| Technical specification | Output speed: 124 1/min Torque: 52Nm Gear coefficient: 2.6 Reducer: Rate: 11.45 Spindle mounted version Ø25 bellows hollow shaft Lubricant: 0.25 l CLP VG680 Mineraloil Motor: Three-phase motor IE3 Rated power: 0.75 kW Motor speed: 1425 1/min Voltage/Frequency: Δ/Y 230/400V 50Hz Rated current: 2,95/1,69A cosφ: 0.74 Insulation class: 155 Protection standard: IP54 Brake B03, 10Nm, 400VAC, Manual brake release position 0 EI02 - Incremental encoder 1024 pulss/rev., 4,5-32VDC, Push-pull (HTL) Signals A, B,0 and reverse Signal connector M23-12pole, position 315A, without socket Motor protection: PTC thermistor sensor Motor connection: terminal box 2xM25+1xM16, position 0A Paint: normal, RAL7031 blue gray Mounting position: M1 |
Please Contact Us to Order to offer competitive prices and delivery time for Helical - S12B DM80GD4 B03MB EI02 TW Motor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
