| BRAND | Aeco |
| Product | SC30P-RE25 T1 |
| Description | Capasitive sensor |
| Internal code | 4699044 |
| Custom code | 85361010 |
| Technical specification | Working voltage: 12 ÷ 240 Vac/dc Output type: AC/DC Function: Changeover relay Actuation type: Delayed Delay range (min): 0 ÷ 1 Sensing distance (mm): 0 ÷ 25 (adjustable) Hysteresis (%Sn): Depends on the switching distance Max. switching frequency: Depends on delay Repeatability (%Sn): < 1 Max. output current: 1 A @ 220 Vac Absorption: < 20 mA @ relay activated Led indicator: Present Shielding: Not embeddable Mechanical characteristics: M30x1.5 Housing material: Plastic Connection type: Cable 2 m Cable type: 5x0.35 PVC Temperature limits: -20 ÷ +70 °C IP rating: IP 65 Weight: 270 g |
Please Contact Us to Order to offer competitive prices and delivery time for Aeco - SC30P-RE25 T1 Capasitive sensor number, also you may ask some other model number is well. We can offer competitive price, and delivery time with wide products distribution network in United Kingdom Industrial products Market.
